5G毫米波28GHz波束形成器 – 4 通道

24.0 GHz to 29.5 GHz 4-Channel Transmit/Receive Beamformer

The ATS29908 is a mmWave 5G transmit and receive beamformer IC with RF range from 24.0 GHz to 29.5 GHz. The RF integrated circuit (RFIC) is highly integrated and contains 4 configurable transmit and receive channels. A horizontal and vertical polarization transmit mode and receive mode control pin is provided for fast switching between transmit mode and receive mode. The vector modulator provides a full 360° phase adjustment range in either TX or RX mode to provide 6bits of resolution for 5.6° phase steps. The ATS29908 can be programmed using a 3-wire or 4-wire serial port interface (SPI), the SPI protocol operates up to 100MHz with fast beam switching and fast beam-state loading.

Product Document

Key Features

RF range: 24.0 GHz to 29.5 GHz

4 configurable transmit and receive channels

High resolution, 6-bit VM for phase control

High resolution, 5-bit DVGA for amplitude control

Matched to 50 Ω, single-ended RF inputs and outputs

Two power supplies required: 2.4 V and 1.2 V

3-wire or 4-wire SPI that supports up to 100 MHz SPI clock speed

Operation Temperature: -40 ~ 95°

Chip die size: 1.3 mm × 3.3 mm

TX gain: 36 dB

TX OIP3: 28 dBm

TX OP1dB：20 dBm

TX PSAT: 21.6 dBm

TX PAEPEAK: 25 %

TX DVGA Dynamic Range: 31.5 dB

TX gain step error: ≤ ± 0.2 dB

Power consumption per channel: 240 mW

Pout@3% EVM：14 dBm

RX gain: 28 dB

RX NF: 3.8 ~ 5.0 dB

RX DVGA Dynamic Range: 31.5 dB

RX gain step error: ≤ ± 0.2 dB

RX P1dB: ＞-23 dBm

RX Dynamic Range: ＞ 62 dB

Applications

mmWave 5G application

Wireless infrastructure

5G NR, RAN and CPE

Phased array antenna

Broadband communication
